PixArt PS5520LT-AA – 5.04MP CMOS, 30fps

PixArt PS5520LT-AA – 5.04MP rolling-shutter CMOS at 30fps; HDR options (RAW10/RAW14, LTM) and MIPI output for smart doorbells, dashcams and AIoT cameras (CSP-39). — Get your camera modules with this sensor on https://www.camemake.eu

Image Sensor Brand
Image Sensor Part Number
Image Sensor Resolution in MP
- 5,04
Image sensor Pixel Size in μm
- 2,2
Image Sensor Technology
- CMOS
Image Sensor Shutter Type
Image Sensor Optical Format in Inch
- 1/2,5
Image Sensor Frame Rate Capabilities
- 30
Image Sensor Maximum Frame Rate
- 30
Image Sensor CFA (Chroma)
Image Sensor Output Format
- RAW10,HDR-RAW14,HDR-LTM-RAW12
Image Sensor Interfaces
Image Sensor Package Type
Image Sensor Black/White
- False
Image Sensor HDR support
- True

Camemaker

Image Sensor Brand	PixArt
Image Sensor Part Number	PS5520LT-AA
Image Sensor Resolution in MP	5,04
Image sensor Pixel Size in μm	2,2
Image Sensor Technology	CMOS
Image Sensor Shutter Type	Rolling Shutter
Image Sensor Optical Format in Inch	1/2,5
Image Sensor Frame Rate Capabilities	30
Image Sensor Maximum Frame Rate	30
Image Sensor CFA (Chroma)	RGB Bayer
Image Sensor Output Format	RAW10,HDR-RAW14,HDR-LTM-RAW12
Image Sensor Interfaces	MIPI
Image Sensor Package Type	CSP-39
Image Sensor Black/White	False
Image Sensor HDR support	True

Image Sensor Brand: PixArt

Image Sensor Part Number: PS5520LT-AA

Image Sensor Resolution in MP: 5,04

Image sensor Pixel Size in μm: 2,2

Image Sensor Technology: CMOS

Image Sensor Shutter Type: Rolling Shutter

Image Sensor Optical Format in Inch: 1/2,5

Image Sensor Frame Rate Capabilities: 30

Image Sensor Maximum Frame Rate: 30

Image Sensor CFA (Chroma): RGB Bayer

Image Sensor Output Format: RAW10,HDR-RAW14,HDR-LTM-RAW12

Image Sensor Interfaces: MIPI

Image Sensor Package Type: CSP-39

Image Sensor Black/White: False

Image Sensor HDR support: True

Documents

PS5520LT_Brief.pdf
