OmniVision OV5640 – 5MP OmniBSI, 30fps

OmniVision OV5640 (MIPI) – 5MP OmniBSI single-chip ISP, rolling shutter, 30fps; outputs YUV/RGB/JPEG/BT.656 for quick integration in IoT and HMIs — Get your camera modules with this sensor on https://www.camemake.eu

Image Sensor Brand
Image Sensor Part Number
Image Sensor Resolution in MP
- 5
Image sensor Pixel Size in μm
- 1,4
Image Sensor Technology
- OmniBSI
Image Sensor Shutter Type
Image Sensor Optical Format in Inch
- 1/4
Image Sensor Frame Rate Capabilities
- 30
Image Sensor Maximum Frame Rate
- 30
Image Sensor CFA (Chroma)
Image Sensor Output Format
- YUV,RGB,Raw 8/10-bit,JPEG,BT.656
Image Sensor Interfaces
Image Sensor Package Type
Image Sensor Black/White
- False
Image Sensor HDR support
- False

Camemaker

Image Sensor Brand	OmniVision
Image Sensor Part Number	OV5640
Image Sensor Resolution in MP	5
Image sensor Pixel Size in μm	1,4
Image Sensor Technology	OmniBSI
Image Sensor Shutter Type	Rolling Shutter
Image Sensor Optical Format in Inch	1/4
Image Sensor Frame Rate Capabilities	30
Image Sensor Maximum Frame Rate	30
Image Sensor CFA (Chroma)	RGB Bayer
Image Sensor Output Format	YUV,RGB,Raw 8/10-bit,JPEG,BT.656
Image Sensor Interfaces	MIPI (2 Lane)
Image Sensor Package Type	CSP
Image Sensor Black/White	False
Image Sensor HDR support	False

Image Sensor Brand: OmniVision

Image Sensor Part Number: OV5640

Image Sensor Resolution in MP: 5

Image sensor Pixel Size in μm: 1,4

Image Sensor Technology: OmniBSI

Image Sensor Shutter Type: Rolling Shutter

Image Sensor Optical Format in Inch: 1/4

Image Sensor Frame Rate Capabilities: 30

Image Sensor Maximum Frame Rate: 30

Image Sensor CFA (Chroma): RGB Bayer

Image Sensor Output Format: YUV,RGB,Raw 8/10-bit,JPEG,BT.656

Image Sensor Interfaces: MIPI (2 Lane)

Image Sensor Package Type: CSP

Image Sensor Black/White: False

Image Sensor HDR support: False

Documents

OV5640_CSP3_DS_2.pdf
